30t Atom Moving Head Cutting Press/Traveling Head Cutting Press/Special Size

Overview

Basic Info.

Model NO.	GRT-T30
Function	Cutting Machine
Ring	Made in Japan(Nok Brand)
Automatic Grade	Automatic
Type	Shoes
Solenoid Valve	Made in Taiwan
Electric Parts	Made in Japan(Omron Brand)
Oil Pump	Made in Taiwan
Transport Package	Wooden Case
Specification	30T
Trademark	GRT
Origin	Yancheng China
HS Code	84532000
Production Capacity	200 PCS/Year

Product Description

30T moving head cutting press Product DescriptionFeatures:1. Gantry frame structure made of profile steel is adopted, with high intensity and without deformation.2. The cutting head can automatically move horizontally, with excellent operating visual field and safe and reliable operation.3. The hydraulic system specially designed is featured by low noise and low oil consumption.4. The lifting position of pressing board can be freely set to reduce idle travel and enhance work efficiency.5. The movement of cutting head is controlled by automatic speed variation to realize flexible movement with high speed and accurate positioning and without impact.6. Differential oil way is adopted to allow rapid and convenient cutting.7. Products of special specifications can be customized.Product Parameters

Main Technical specification
Model	GRT-T30
Maximum cutting force	30T
Working table size	1600*500mm/1800*500mm/2000*500
Cutting head size	500*500mm
Adjustable stroke	5-150mm
Motor power	2.2KW
Electric Supply Voltage	3x440/415/400/380/220/200V, 50/60 Hz
Machine dimensions	2200*720*2000mm
G. W	1600kg

REMARK:MY FACTORY CAN MAKE THE MACHINE ACCORDING YOUR REQUEST,FOR EXAMPLE,THE WORKTABLE SIZE,CUTTING HEAD SIZE.Detailed Photos
